| YOYO OUTDOOR | |
|---|---|
| Material | Cast aluminium |
| Finish | Raw untreated |
| Raw anodized | |
| Colors | White RAL 9010 |
| Black RAL 9005 | |
| Alu-grey RAL 9006 | |
| Yellow RAL 1032 | |
| Orange RAL 2003 | |
| Blue-green RAL 6004 | |
| Squirrel grey RAL 7000 | |
| Shade | Opal-white acrylate PMMA |
| Mounting | Ceiling or wall |
| Connection | max 2 cables, 5x1.5 mm2 into 5-pole terminal block 2x2.5 mm2 |
| Classification | IP65, class II, IK09 |
| Weight | 1,9 kg |
| LED type | 244 mm board |
|---|---|
| Operationel life | min 50,000 hours at ta 25ºC, L80B10 |
| Color temperature | View configurator |
| Color rendering | View configurator |
| Color accuracy | 3 steps SCDM |
| Driver | LED driver, 20W, dimming optional |
|---|---|
| In rush current | max 5 A (50% after 50 µs) |
| Nominel voltage | 220-240V |
| Operational input voltage, AC | 198-264 Vac |
| Nominal Voltage, DC | 170-280 |
| Nominal frequency range | 50-60 Hz |
| Surge protection | L/N-GND: 4 kV, L-N: 2 kV |
| Operationel levetid | min 100.000 timer |
| Dimming/control | 0-10, DALI |
