Sky Park Large is designed for larger environments and public spaces where proportion and scale play a key role. The increased height gives the luminaire a strong visual presence, enhancing wayfinding and the sense of safety while preserving its elegant design.
| SKY PARK | |
|---|---|
| Material | Cast aluminium |
| Finish | Raw anodized |
| Graphite grey: YW355F, Akzo Nobel | |
| Silver grey: Y2370I, Akzo Nobel | |
| Corten brown: YX355F, Akzo Nobel | |
| Black: Black RAL 9005 Fine Texture YN305F (Noir 900) | |
| Screen | Clear polycarbonate with UV-resistant acrylate on both sides |
| Mounting | Post top/pipe: Ø60 or Ø76 x H100 mm |
| H05VV-F 2x1mm² | |
| Connection | In the post |
| Classification | IP66, class II, class I |
| Impact resistance | IK10; with Zhaga socket IK09 |
| Corrosion class | C4, C5 |
| Weight | 12 kg |
| Wind-sweeping area | 0.218 m2 (laterally) |
| LED | |
|---|---|
| Operational life | min 100,000 hours at ta max 25° C, L100B10 |
| Colour temperature | View configurator |
| Colour rendering | View configurator |
| Colour accuracy | 3 steps SDCM |
| LED BioAdaptive | |
|---|---|
| Service life | min 100.000 hours at ta max 25ºC, L90B10 |
| BioAdaptive Warm (3000-1800K) | |
| BioAdaptive Dim2Warm (3000K) | |
| Colour rendering | CRI 90 |
| Colour accuracy | 3 steps SDCM |
| Driver, Low lumen | Xi CR 40W 0.2-1.05A |
|---|---|
| Inrush current | 35.4 A (50% efter 122 µs) |
| Driver, High lumen | Xi CR 75W 0.2-1.05A |
|---|---|
| Inrush current | 54.3 A (50% efter 138 µs) |
| Nominel voltage, AC | 230 Vac |
| Nominel frequency range | 50-60 Hz |
| Surge protection | L/N-GND: 10 kV, L-N: 6 kV |
| Operationel service life | min 100.000 hours |
| Dimming | 5-steps dimming within the lumen intervals |
| Alternatively | DALI-2 (4/5-conductor cable), LineSwitch or via Zhaga book 18 socket, D4i |
