Simplicity by design is the principle behind Sticks 900 created by schmidt hammer lassen. The lines of the black or grey-enamelled aluminium housing are continued in single or double light slots in opalised plastic. At daylight, Sticks is simply part of the environment; at night, light predominates and the surroundings step into character.
Sticks is available with base for embedment or flanged base for mounting on solid ground.
| STICKS 900 | |
|---|---|
| Material | Aluminium |
| Coating | Graphite grey: YW355F |
| Silver grey: Y2370I | |
| Black: RAL 9005 | |
| Black: Noir 900 Sablé, SN351F | |
| Corten brown: YX355F | |
| Shade | Opal-white, impact-resistant acrylate |
| With single or double light slit | |
| Mounting | Rooted or flanged base |
| Connection | Max two cables, 5 x 6 mm2 |
| Driver and 4A fuse in the bollard | |
| Classification | IP55 , class II; use code for class I |
| Weight | 15.5 kg |
| LED type | Citizen Array CALD0414-M8L1 |
|---|---|
| Total consumption | |
| Single light slit | 8 W (500 mA) or 11 W (700 mA) |
| Double light slit | 15 W (500 mA) or 20 W (700 mA) |
| Operational life | min 50,000 hours at ta max 25°C |
| Colour temperature | View configurator |
| Colour rendering | View configurator |
| Colour accuracy | 3 Steps SDCM |
| Driver | LED driver, 20 or 32 W |
|---|---|
| Operational life | min 100,000 hours |
Sticks - and Square - are designed in 1999, and both designs have pathed the way within their fields of application.
The simple, minimalist design enhances the form, and the light is not dominant.
