H+M PENDANT

Please choose

The H+M Pendant is used for general illumination of halls, shops and other large rooms as well as spot light on working and dining tables.

Like the other luminaires in the H+M family, the pendant is available in two sizes and three standard colours.

Specifications

Ø 300

hm_pendel300_skitse

Luminaire

H+M PENDANT 300
Material Aluminium
Coating White, black, or graphite grey
Shade Opal-white polycarbonate
Lead 3 m PKAJ, white or black
Support heat resistant to 140°
Connection 3 x 4 mm²
Classification IP20, class I or II
Weight 1-3 kg


LED and driver data

LED type 244 mm board
Operational life min 50,000 hours at ta max 25° C, L80B10
Total consumption 11 or 15 W
Colour temperature 2700, 3000, or 4000 Kelvin
Tunable White: 2700-6500 Kelvin
Colour rendering min 90 Ra
Colour accuracy 3 steps SCDM
Output ratio 80%

Driver LED driver, 20 W, dimming optional
Inrush current max 5 A (50% after 50 µs)
Operational life min 50,000 hours

Variants



Item No. H+M 300 pendant
1812- 11 W LED, 350 mA
1813- 15 W LED, 500 mA




Combine with

Select colour, colour temperature, etc. in the table below.

Colour Shade
1 = white empty = polycarbonate
3 = black
4 = graphite grey

Colour temperature Dimming
927 = 2700 K, 90 Ra empty = no dimming
930 = 3000 K, 90 Ra V = 1-10 V
940 = 4000 K, 90 Ra D = Dali
9WD = tunable white, Dali, 90 Ra

Classification Lead colour
empty = class I empty = white
K = class II Y = black


Example Item No.: 1812-3930D = H+M pendant Ø300, 11 W LED, black, 3000 K, 90 Ra, Dali

hm_pendel300_skitse

Luminaire

H+M PENDANT 300
Material Aluminium
Coating White, black, or graphite grey
Shade Opal-white polycarbonate
Lead 3 m PKAJ, white or black, SSH 180°
Support heat resistant to 140°
Connection 3 x 4 mm²
Classification IP20, class I or II
Weight 1-3 kg


Lamp type

E27 max 57 W, max length: 95 mm


Variants



Item No. H+M 300 pendant
1006- max 57 W, max length 95 mm




Combine with

Select colour, shade, etc. in the table below.

Colour Classification
1 = white empty = class I
3 = black K = class II
4 = graphite grey

Lead colour
empty = white
Y = black



Example Item No.: 1006-3 = H+M pendant Ø300, E27, black

Media & downloads

DesignChristian Hvidt Design

H+M Pendant, designed by Christian Hvidt in 1976, is out-and-out retro with modern technology. The height of the luminaire is reduced by 30 mm, and the new minimalist version appears light and blend into the preferred style.
The H+M luminaires are classics within interior lighting and rank high as some of the most downloaded fittings in the 3D portal BimObject

Christian Hvidt is active as a freelance designer for Danish and international companies, especially within furniture and lighting.
